Work space dimensions: 800*400mm
Vertical table dimensions: 1020*225mm
T-slots,work table: (6)14*63mm
T-slots,vertical table: (3)14*63mm
Table load capacity: 200Kg
Travel: Longitudinal(X): 500mm
Transverse(Y): 400mm
Vertical(Z): 400mm
Spindle axis-to-table surface distance:
Horizontal spindle: 145-545mm
Vertical spindle: 50-450mm
Speed range: (2)40-2000rpm
Spindle mount: ISO40
Feeds X Y Z axis: 10-1000mm/min
Rapid feed: 1200mm/min
Quill stroke: 60mm
Main motor rating: 3.7Kw
Feed motor rating: X:7.7N.M
Y:7.7N.M
Z:10N.M
Dimensions (L*W*H): 1500*1700*1800mm
Weight: 1500kg
