Drilling capacity: Φ25mm(1″)
Face milling capacity: Φ63mm(2-1/2″)
End milling capacity: Φ20mm(3/4″)
Distance from spindle nose to table: 445mm(17-1/2″)
Min.distance from spindle axis to column: 203mm(8″)
Spindle travel: 80mm(3-1/8″)
Spindle taper: MT3 or R8
Step of spindle speed: 6 steps
Range of spindle speed 50Hz: 95-1420 rpm
60Hz: 115-1700 rpm
Swivel angle of headstock perpendicularly: ±90°
Table size: 520×160mm (20-1/2″×6-5/16″)
Forward and backward travel of table: 140mm(5-1/2″)
Left and right travel of table: 290mm(11-3/8″)
Motor power: 0.37KW
Net weight/gross weight: 180kg/240kg
Packing size: 680×750×1000mm
