Max. drilling capacity Φ45mm
Max. tapping capacity: 20mm
Max. face milling capacity: Φ80mm
Max. end milling capacity: Φ32mm
Max. distance from spindle nose to table: 400mm
Min.distance from spindle axis to column: 285mm
Spindle travel: 130mm
Spindle taper: MT3, MT4 or R8
Range of spindle speed: 100-530,530-2800 r.p.m
Swivel angle of headstock (vertical): ±45°
Table size: 800×240mm
Forward and backward travel of table: 175mm
Left and right travel of table: 500mm
Motor power: 1.5kw
N.W/G.W: 325/375kgs
Packing size: 770×880×1160mm
