Spindle taper: MT4/ISO40
Distance vertical spindle to table: 100-500mm
Distance horizontal spindle to table: 0~400mm
Distance spindle to column: 240~710mm
Spindle speeds range: (8 steps)90-2000(vertical)
(12 steps)40-1300(horizontal)r/min
Automatic Feed Series sleeve: 120(vertical)mm
Table size: 1370×320mm
Table travel: 800/320/400mm
Distance horizontal spindle to arm: 175mm
Table feeds range(x/y): 40-605(8 steps)(max.810)mm/min
T of table (no./width/distance): 3/14/70mm
Main motor: 2.2kW
Motor of table power feed: 1000W
Coolant pump motor: 40W
N.W/G.W.: 1550/1700kg
Overall dimension: 1700×1480×2150mm
