Output voltage: 24V
Output current: 1-100A
Discharge mode CC , CP
Accuracy & resolution: ≤ ±0.5%, 0.01V
DC voltage measurement
Internal current range: 2-300A
Accuracy & resolution: ≤ ± 1%; 0.1A
Cell voltage Range: 0-15V
Accuracy & resolution: ≤ ± 0.5%; 0.01 V
AC power supply
Power Supply : AC 220V, 50Hz
Cooling mode: Air Cooling
Communication & storage
Storage mode: SD card and internal storage
Internal memory: 16MB flash or optional
Display: 7 inch touch screen
High-Voltage insulation test:
- Input-The enclosure: 2200Vdc 1min
- Input-Output: 2200Vdc 1min
- Output- The enclosure: 700Vdc 1min
Environment
Work temperature: -5～50℃
Storage temperature: -40～70℃
Humidity : 5%～95% RH
Altitude: Below 4000 m
Working noise : <60 dB
Dimensions of host machine: 55x25x44 mm
Net weight: 23 kg
