Voltage monitoring range: 2V battery 0~3.000V; 12V battery 8.000~16.500V
Voltage monitoring accuracy: 0.05%, resolution: 1 mV
Internal resistance measurement range: 0~65535μΩ; accuracy: ≤2%; repeat measurement accuracy: ± 1%
Range of current monitoring: 0 ~ ± 1000A (50A, 150A, 300A, 500A, 1000A is optional); accuracy: ≤1%; resolution: 0.1A
Temperature monitoring range: -55℃~+125℃; accuracy: 0.5℃
Voltage equalization degree: <20 mV
SOC or SOH accuracy:＜10%
Data refresh speed: <1s
Input insulation resistance: ≥10MΩ, 600V
Size:
- Display host: 198×140×46 mm (excluding wiring terminals and fixtures)
- Data collector: 151×82×27 mm (excluding terminals and fixtures)
- Single module: 90.5×54.5×20.6 mm (excluding terminals)
Work environment: Temperature: -20℃~60℃; humidity: 10%~80% RH, no condensation
