1. Measurement range: 0～2999.9μΩ
2. Resolution: 0~99.99, 0.01μΩ; 100.0~2999.9, 0.1μΩ
3. Measured current: DC 50A, 100A, fixed output.
4. Accuracy : ±(0.5% rd+2d)
5. Continuous working time: 5s~599s
6. Display: LCD
7. Communication mode: U disk
8. Power supply: AC220V±10% 50Hz
9. Power of the whole machine:600W
10. Maximum storage record: 200
11. Service conditions: temperature- 10℃～40℃ humidity≤80 %RH
12. Dimension: 360×300×250 mm³
13. Weight: 8kg (the accessories not included)
Product features:
1. High current, adopts new switching power techniques, can output current long time and continuously , overcome the malpractice of instantaneous current of the impulse type power, can effectively break through the oxide film of the switch contact, get accurate test result.
2. High stability, under strong interference, the last number displayed by the LCD within the range of ±1, with steady reading and good reproducibility.
3. High precision: adopts double channels high-speed 16bits Σ－Δ AD to sample, digital signal processing technique, the maximum resolution up to 0.01μΩ.
4. Intelligent: use high performance CPU, system can switch the measurement range according the size of the signal when testing, ensure the accuracy. The over-temperature protection circuit can auto stop output the current when the device exceeds the rated temperature to ensure the safety.
5. High quality: key components adopts imported components, uses temperature compensating circuit in perfect design which eliminates the effect to test result by temperature, meanwhile strengthen the resistance to shock by using the military connector.
6. Powerful: current could be 50A, 100A, measurement time 5s~599s, more powerful than other equipments.
7. Friendly man-machine interface: enter the data by rotating mouse, easy and convenient, can set the data, time by yourself, save and print the test result in time.
8. U-disk: Store the data to U disk by U-disk interface, combining PC software for further analysis and processing of the measurement data.
9. Easy to carry: small in volume, light in weight.
