1. Measurement range: 0～1999μΩ
2. Resolution: 1μΩ
3. Test Current: DC 50A, DC 100A, DC 150A, DC 200A, four fixed outputs.
4. Work Mode: continuous
5. Measurement Accuracy：0.5%±1d
6. Display: three and a half LCD
7. Power Supply：AC220V±10% 50Hz
8. Work Environment：Temperature： -10℃～40℃ Humidity：≤80 %RH
9. Dimension：380 mm×350 mm×260 mm
10. Weight：5kg（Accessories excluded）
Product features:
1. High current: For latest power supply technology, the tester can continuously output high current which overcomes the weakness of instantaneous current produced by pulsed power. It can effectively breakdown/puncture the oxide layer of the switches and then get precise results.
2. Strong anti-interference ability: The last number of test data will stably show in the LCD screen only with ±1 error even in strong Interference situation.
3. Long service life: All the precise resistances used in the tester can reduce the temperature’s impact on the measurement results and military connectors can enhance vibration resistance.
4. Convenience: Small size, light weight.
