Function: insulation resistance test, DAR, PI, AC/DC voltage test
Power Supply: DC 1.5V LR14×6pcs
Rated Voltage: 50V / 250V / 500V / 1kV / 2.5kV
Insulation Resistance Range: 0.1MΩ～200GΩ
Voltage Range: AC/DC 0V ~ 750V
Shout Circuit Current: 2mA Max
Max Capacitive Load: 1uF
Dielectric Absorption Ratio Test (DAR): Yes
Polarization Index Test (PI): Yes
Shift: Turn the shift rotary knob to select the appropriate gear
Display Mode: 4 digital LCD display
Measurement indication: LED flicker and buzzer ring in measurement
LCD Size: 108mm×65mm
Meter Dimension: 212mm×175mm×76mm
Weight: 1230g
Working Temperature and Humidity: -10℃ ~ 40℃; below 80%RH
Storage Temperature and Humidity: -20℃～60℃; below 70%RH
