- Working condition: Temperature: 0℃～40℃; Relative humidity: ≤85%
- Measurement range: Six-gear range
+ 1μΩ～20mΩ
+ 20mΩ～200mΩ
+ 0.2Ω～2Ω
+ 2Ω～20Ω
+ 20Ω～200Ω
+ 200Ω～2kΩ
- Measuring accuracy: Class 0.2
- Max resolution: 1μΩ
- Constant current source:
+ 1A(1μΩ～20mΩ、20mΩ～200mΩ、0.2Ω～2Ω)
+ 100mA(2Ω～20Ω)
+ 10mA(20Ω～200Ω)
+ 1mA(200Ω～2kΩ)
- Working voltage
+ DC: 11V～14V
+ AC: 220V
- Dimension: 365*330*180mm3
- Weight: 5kg
Accessories
- Host
- Test Wire: 2
- Ground wire
- Fuse
- Power Cord
- Manual, Report, Certificate
