Width: 17 mm
Height: 13.5 mm
Length: 22 mm
Core Type: Wirewound
Shielding: Shielded
Tolerance: 20 %
Inductance: 15 uH
Application: High Current
Termination: Standard
Unit Weight: 16.880 g
Core Material: Manganese Zinc (MnZn) Ferrite
Qualification: AEC-Q200
Mounting Style: PCB Mount
Termination Style: Radial
Maximum DC Current: 20.6 A
Saturation Current: 12.9 A
Maximum DC Resistance: 5 mOhms
Self Resonant Frequency: 13 MHz
Maximum Operating Temperature: + 75 C
Minimum Operating Temperature: - 40 C
