Height: 14.5 mm
Length: 14.5 mm
Diameter: 10.5 mm
Core Type: Wirewound
Shielding: Unshielded
Tolerance: 5 %
Inductance: 2.2 mH
Lead Spacing: 5 mm
Core Material: Wirewound
Lead Diameter: 0.7 mm
Mounting Style: PCB Mount
Test Frequency: 10 kHz
Termination Style: Radial
Maximum DC Current: 500 mA
Saturation Current: 580 mA
Maximum DC Resistance: 2.5 Ohms
Self Resonant Frequency: 820 kHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
