Capacity: 50kg~300kg
Non-linearity: ≤0.2%F.S.
Repeatability: ≤0.05%F.S.
Zero balance: ±5%F.S.
Operating temp range: -20~80°C
Compensated temp range: -10~40°C
Insulation: ≥2000MΩ/100VDC
Recommended excitation voltage: 12-30 VDC
Safe load limit: 300%F.S.
Temp effect on output: ≤0.5%F.S./10°C
Temp effect on zero: ≤0.5%F.S./10°C
Long-term crosstalk error: ≤0.5%F.S.
Protection class: IP65
Cable size: φ3*3m (two cable)
Details
