Capacity: 0-30T
Material: Alloy steel Stainless steel
Nonlinearity: 0.1% F.S.
Rated output: 2.0±0.05mV/V
Recommended excitation: 5-12VDC
Maximum excitation: 15VDC
Protect class: IP66
Compensated temp range: -10~40°C
Hysteresis: 0.05% F.S.
Operating temp range: -20~80°C
Repeatability: 0.05% F.S.
Insulation: ≥2000MΩ
Input impedance: 750±30Ω
Output impedance: 700±5Ω
Creep(30min): 0.05% F.S.
Temp effect on output: 0.05%F.S./10°C
Zero balance: ±2%F.S.
Temp effect on zero: 0.05%F.S./10°C
Limit load: 150%
Breaking load: 200%
Cable size: Ø5 x3m
Life: Full scale more than 1 million times
Cable Connection: Ex+: Red；Ex-: Black；Sig+: Green；Sig-: White
Detail
