Capacity: 0-500N.m
Driving voltage: 12VDC
Zero balance: ±2% F.S.
Rated output: 1.0~2.0 mV/V
Limit load: 120%
Temp effect on zero: ±0.1% F.S./10°C
Response frequency: 100Hz
Compensated temp range: -10~40°C
Material: Alloy steel
Operating temp range: -20~80°C
Combined accuacy: 0.2% F.S.
Insulation: ≥5000MΩ/100VDC
Input impedance: 700±10/350±10Ω
Output impedance: 700±5/350±5Ω
Cable Connection: Ex+: Red；Ex-: Green；Sig+: Yellow；Sig-: White
Detail
