Non-linearity: ≤0.2%F.S.
Repeatability: ≤0.2%F.S.
Zero balance: ±2%F.S.
Rated output: 1.0±10%mV/V
Communication: SPI
Sampling frequency: 2000Hz
Temp effect on output: 0.2%F.S./10°C
Temp effect on zero: 0.2%F.S./10°C
Insalution: ≥2000MΩ/50VDC
Operating voltage: 12-30VDC
Compensated temp range: -10~40°C
Operating temp range: -20~80°C
Limit load: 200%F.S.
Breaking load: 500%F.S.
Protection class: IP64
Torional rigidity: 80(KNm/rad)
Cable size: φ2*1m
Detail
