Width: 101.6 mm
Height: 39.1 mm
Length: 152 mm
Industry: Medical, Industrial
Approvals: CSA, EN60950-1, IEC60601-1, IEC60950-1, TUV, TUV 60601-1, UL60601-1, UL60950-1
Compliance: CSA, EN60950-1, IEC60601-1, IEC60950-1, TUV, TUV 60601-1, UL60601-1, UL60950-1
Efficiency: 95 %
Output Power: 250 W
Input Voltage: 85 VAC to 275 VAC
Mounting Style: Chassis
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 4 kVAC
Number of Outputs: 1 Output
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 20.8 A
Output Voltage-Channel 1: 12 VDC
Operating Temperature Range: - 20 C to + 70 C
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 20 C
