Width: 31.7 mm (1.248 in)
Height: 20 mm (0.787 in)
Length: 78.7 mm (3.098 in)
Industry: Industrial
Approvals: CSA/cUL, EN60950-1, IEC60950-1, UL60950-1
Compliance: CSA/cUL, EN60950-1, IEC60950-1, UL60950-1
Dimensions: 78.7 mm
Efficiency: 83 %
Unit Weight: 60 g
Output Power: 30 W
Input Voltage: 85 VAC to 264 VAC
Mounting Style: Chassis
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 3 kVAC
Number of Outputs: 3 Output
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 3 A
Output Current-Channel 2: 630 mA
Output Current-Channel 3: 630 mA
Output Voltage-Channel 1: 5 VDC
Output Voltage-Channel 2: 12 VDC
Output Voltage-Channel 3: - 12 VDC
Operating Temperature Range: - 20 C to + 70 C
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 20 C
