Direct access to our certified experts
Width: 76.2 mm (3 in)
Height: 21 mm (0.827 in)
Length: 127 mm (5 in)
Industry: Medical, Industrial
Approvals: ANSI/AAMI, CSA, EN60601-1, EN60950-1
Compliance: ANSI/AAMI, CSA, EN60601-1, EN60950-1
Efficiency: 94 %
Unit Weight: 230 g
Output Power: 225 W
Input Voltage: 90 VAC to 264 VAC
Mounting Style: Panel
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 4 kVAC
Number of Outputs: 1 Output
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 9.38 A
Output Voltage-Channel 1: 24 VDC
Operating Temperature Range: - 20 C to + 70 C
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 20 C
