XP Power FHSAA06A1FR Power Line Filters EMC FILTER, CHASSIS MOUNT, ITE, 6A

Name: XP Power FHSAA06A1FR Power Line Filters EMC FILTER, CHASSIS MOUNT, ITE, 6A
Brand: XP Power

ModelFHSAA06A1FR

Contact

Quantity

Secure Checkout

Quality Engagement

Easy change and return

Delivery Available

Width: 24 mm

Height: 17.5 mm

Length: 44 mm

Approvals: EN60939-2, ANSI/UL1283

Compliance: EN60939-2, ANSI/UL1283

Inductance: 2 x 0.8 mH

Capacitance: 0.1 uF, 6600 pF

Filter Type: 1-Phase EMI/EMC Filter

Unit Weight: 43 g

Current Rating: 6 A

Mounting Style: Chassis Mount

Voltage Rating: 250 VAC

Leakage Current: 600 uA

Termination Style: Quick Connect

Operating Frequency: 0 Hz to 400 Hz

Maximum Operating Temperature: + 110 C

Minimum Operating Temperature: - 40 C
