Impact high voltage: 0~15kV
High voltage partial pressure: 2.5 level
Built-in capacitor: 8μF
Discharge power: 0~900J
Output voltage polarity: negative polarity
Impact power: 400W
Working mode: Selectable or adjustable impulse rate and single shot
Minimum output current in DC mode: 16mA at 15kV
Length of test cables: The high-voltage output line of the pull-rod type high-voltage pulse generator is 2 meters long, the ground line is 3 meters long, and the power line is 1.8 meters long.
Over temperature protection: 65°C
Over current protection: 8mA (more than 3 seconds)
Volume (mm): 540L×300W×450H
Weight: not more than 25kg
Power supply: AC220V±15%, 50Hz±2Hz (60Hz)
Ambient temperature: -20℃~+60℃
