Channels: 2 electrical signal interfaces, 1 external synchronization interface
Sampling rate: 0.5M, 1M, 2.5M, 5M, 10M, 20M (selectable)
Sampling accuracy: 12bit
Range switching: 60dB, 40dB, 20dB, 0dB, -20dB (5 ranges total)
Band range: 20k-100kHz, 80k-200kHz, 40k-300kHz
Range nonlinearity error: 5%
Sensitivity: 0.1pC
Testable capacitance range: 6pF ~ 250μF
Test power frequency range: 50 ~ 400Hz
Display: 7" TFT true color touch LCD (800×480 resolution)
Physical storage: 256MB DDR2, 16G SD card (expandable to 32G)
Interfaces: RS232 / USB / electrical signal / SMA / SD card / network / ground
CPU: 533MHz, WINCE6.0 OS
Dimensions: 350mm × 245mm × 175mm
Weight: 5.8kg
