Width: 6.50 mm
Height: 2.30 mm
Length: 9.43 mm
Fall Time: 23 ns
Rise Time: 17 ns
Technology: Si
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 P-Channel
Qg - Gate Charge: 7.8 nC
Number of Channels: 1 Channel
Transistor Polarity: P-Channel
Pd - Power Dissipation: 25 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 8 ns
Typical Turn-Off Delay Time: 22 ns
Id - Continuous Drain Current: 17 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 9.6 S
Rds On - Drain-Source Resistance: 52 mOhms
Vds - Drain-Source Breakdown Voltage: 40 V
Vgs th - Gate-Source Threshold Voltage: 3 V
