Circulation system: Water jet pump circulation/External closed circulation
Operating temperature range: RT+15~100°C
Temperature adjustment accuracy: ±0.01°C (water: RT+15°C~80°C)
Temperature indication unit: 0.1℃
Circulation Pump: Water jet pump circulation
Pump max. flow (50/60Hz): 14/15L/min. (Circulation pressure loss when below 10kPa)
Pump max. lift (50/60Hz): 2.8/3.4m (water flow about 0.5L/min)
Heater: 1kW
Ambient temperature range: 5~30°C
Temperature control/system: PID control by microprocessor
Sensor: W sensor: Pt 100Ω A-class (for temperature control)+ K-thermocouple (for overheat prevention) double sensor
Accessories: Hose nipple (1/2×ø14mm) 2pcs.
Internal dimensions（W×D×H mm）: 239×299×200mm
External dimensions（W×D×H mm）: 310×396×607mm
Remarks(dimensions): Effective tank dimensions W227×D150×H200mm（Frontage corner R34） Tank height 307㎜（rubber height included）Internal capacity13L（Liquid volume approx.10L）
Power Source: AC220V 5A Single-phase with step down transformer
Weight: 20kg
