Circulation Method: External closed system circulation
Cooling Method: Water-cooled type
Temperature Control Range: 0 - 80℃ (Operation of entire freezer)
Operating Temperature Range: 5 - 35℃
Temp. Adjustment Accuracy/Temp. Fluctuation: ±0.1℃ (JTM K05)/ 0.6℃ at 20℃ (JIS)
Temperature Display Unit: 0.1℃
Cooling Capacity: Approx. 3,200W (at Liquid Temp. 20°C, Room Temp. 23℃, Water Supply Temp. 20℃)
External Circulation Flow Rate/Pump Max. Lift: Approx. 19/22ℓ/min/Approx. 14.5/20.5m (50/60Hz)
Water Tank Material: SUS304
Water Tank Dimension: W170×D370×H360mm
Water Tank Capacity: Approx. 17L
Exterior Material: Chrome-free electrogalvanized steel plate, Chemical resistance coating
Refrigerator: Swing Type Compressor (Inverter control)/R410A
Heater: 3,200W
Temperature Sensor: Pt100Ω(Temp. control), T thermocouple (Water temp., Evaporation temp.), K thermocouple (Overheat)
Circulation Pump: 180/216W
Circulation System Material: Stainless steel joint, Ethylene propylene hose
Condenser: Plate type heat exchanger/SUS316
External Circulation Nozzle: Nozzle is option, Rc1/2
Water Supply Facility: Temp.: 10-33℃, 15L/min or more, Water Pressure: 3 to 7kg/cm2
External dimensions（W×D×H mm）: 420×650×1021mm
Power Source: AC220V
Single-phase with step down transformer
Weight: 95kg
