Solvent recovery system: Capacitor + freezer
Circulating gas: N2 gas (sealed circulation when connected to ADL311SA or GB-210A)
Circulating volume flow: 0.12 to 0.65m3/min
Compressor (for spraying): Linear compressor integrated
Circulation blower: Roots blower
Solvent recovery container: 2L flask
Freezer: Air-cooled condensation full-sealed type: 400W R404A (GWP:3920)
Solvent recovery mechanism: Capacitor cooling mechanism
Filter: Cartridge filter
Instruments: Cooling trap temperature display monitor Filter differential pressure meter (Monitor for clogging of filter) O2 density display monitor Blower wind amount adjusting volume
O2 sensor: Solid electrolyte (Zirconium) limit current type
Pump: For circulation to measure Oxygen
Safety device: O2 density meter, Flammable gas alarm, Electric leakage breaker, N2 gas forced introduction (when removing nozzles)
Required N2 amount: 15 L/h at 0.1 MPa
Accessories: Set of connection parts, anti-seismic clamps, interface cable, sample gas for gas alarm inspection, 2L flask
External dimensions（W×D×H mm）: 700×950×1500mm
Power Source: AC200-AC240V Single phase AC200〜240V 5A（15A）
Weight: 130kg
