Exterior: Cold-rolled steel plate (chemical resistance baking finish)
Interior: Non-asbestos and non-combustible decorative board (Baffle plate: multi slit system)
Working surface material: Ceramitite (S)
Glass window: Tempered glass 5mm (Up&Down : Balance weight/L&R : Rail slide)
Water faucet: Single type 1pc
Outlet: AC115/220V with dual grounding wire (dropout prevention) 1pc
Fluorescent lamp: 32W 1set
Safety feature: Exhaust delay timer, Door falling prevention stopper, Flow monitor, Emergency exhaust switch
Atomosphere conditions: Room temp. : 5 to 35 oC, Room humidity : 20 to 80% (No condensation)
Option: Gas tap, LED, Safety mechanism
Standard discharge air quantity: 6 to 17 m3/min
Static pressure: 58Pa (at 17 m3/min)
Motor damper: Approx. 7 sec from fully open to fully closed (50/60Hz)
External dimensions（W×D×H mm）: 1500×750×2605mm
Power Source: AC115/220V
Weight: 320kg
