Power Supply: AC100～240V，50/60Hz 50W
Working Environment:
Temperature: 10~35℃
Humidity: ≤85％
Display: 7 inch color touch screen
Measuring range: 0～18mm
Resolution: 0.01mm
Indication error: ±0.03mm or ±0.5％
Indication variability: ≤0.03mm or ±0.5％
Parallelism between measuring surfaces: ≤0.035mm
Contact area: 1000±20 mm²
Contact pressure: 20±0.5kPa
Probe descending speed: 0.5～10mm/s Adjustable
Print: Built-in thermal printer
Communication Interface: RS232 (Default) Dimension: 320×310×400 mm
Net Weight: ≤26.5kg
