Power Supply: AC100～240V，50/60Hz 100W
Working Environment:
Temperature: 10~35℃
Humidity: ≤85％
Display: 5 inch color touch screen
Measuring range:
Tensile 1～300N（customizable）
Compression 30～3000N（customizable）
Accuracy: ±1% (Range 5%～100%)
Resolution:
0.1N（Tensile)
1N（Compression）
Stretching speed: 1～100 mm/min
Return speed: 1～500 mm/min
Distance between tension chucks: 0～300 mm Adjustable
Standard width of tension chuck: 15mm（customizable）
Pressure panel: Round pressure plate (diameter 15cm)（customizable）
Stroke: 300 mm
Print: Built-in thermal printer
Communication Interface: RS232 (default) (USB, WIFI optional)
Dimension: 550×415×790 mm
Net Weight: 70 kg around
