Power Supply: AC220V±10%, (50/60)Hz，150W
Working Environment:
Temperature(10~35)℃
Humidity≤ 85％
Display: 7 inch color touch screen
Measuring Range: 50～1600kPa，customizable（10～5000）N
Indication error: ±0.5％(Range 5%～100%)
Resolution: 0.1kPa
Refueling speed: 95±5 ml/min
Air pressure adjustment: 0.15MPa
Hydraulic system tightness: Upper limit of measurement, 1min Pressure drop＜10％Pmax
Upper clamp ring aperture: 30.5±0.05 mm
Lower clamp ring aperture: 33.1±0.05 mm
Print: Built-in thermal printer
Communication Interface: RS232 (default) (USB, WIFI optional)
Dimension: 470×315×520 mm
Net weight: 56kg around
