Measurable conductor size:Max. φ18 mm
Measuring range:AC 0 to 50 Arms,
Output voltage:AC 0 to 500 mVrms (10 mV/A)
Accuracy (sine wave input):Phase:Within ±2.0 deg (at 0.5 A to 50 A, 40 Hz to 3.5 kHz)
Temperature & humidity range (guaranteed accuracy):23 ±5°C, 85%RH or less(no ondensation)
Rated voltage between circuit and ground:AC 300 Vrms Max.
Operating temperature & humidity range:0 to 50°C, 85%RH or less (no ondensation)
Storage temperature & humidity range:-20 to 60°C, 90%RH or less (no ondensation)
Temperature coefficient:0.05% f.s./°C (0 to 50°C)
Maximum allowable input:AC 130 Arms continuous (50/60Hz)
Influence of the conductor location:Within ±0.5% rdg (1 to 50 A, 45 Hz to 1 kHz)
Influence of the external magnetic field: 0.1 A equivalence or less (400 A/m, 50/60Hz)
Output impedance:Approx. 18 Ω
Withstand voltage:AC 3.7 kVrms / 1 minute Between jaw and case, case and output terminal, output terminal and jaw.
Recommended calibration period:1 year
Environmental condition:Altitude up to 2000 m, in-door use
Dimension:52(W)×106(H)×25(D) mm (excluding projections)
Cable length:Approx.3m
Output terminal:MINI DIN 6PIN
Weight:Approx.170g
Accessory:Instruction manual, Output cable (M-7199)
