Wavelength (nm): 1310/1550 ±25 (SM); 850/1300 ±30 (GI)
Light emitting device: LD (SM), LED (GI)
SM (LD) Spectral width (nm): <5 / <10
GI (LED) Spectral width (nm)(FWHM): 40 (typ)/140 (typ)
Optical output level (dBm): SM: −3 ±1, GI: −20 ±1
Level stability (dB): SM: ±0.05, GI: ±0.1
Modulation mode: CW, CHOP (270 Hz, 1 kHz, 2 kHz)
Applicable fiber: SM (ITU-T G.652), GI (50/125 µm)
Optical Connector: SC, FC, 1.25 mm dia. ferrule
Laser class: Class 1
Display: 5.7 inch color LCD (640×480)
Loss test mode (only with /SPM or /HPM): Auto loss test, Loopback test, Multi-core loss test
Internal memory: 128 MByte
External interface: USB 1.1 Type A and Type B (mini) 1 ea.
AC adaptor 100 to 120 VAC, 200 to 240 VAC, 50/60 Hz
Battery: Li-ion, duration 6 hour, charging time 5 hours
Operating environment: Temperature 0 to 45ºC (0 to 35ºC when charging the battery), Humidity 85% RH or less (no condensation)
Storage environment: Temperature −20 to 60ºC, Humidity 85% RH or less (no condensation)
Dimensions: 217.5 mm (W) × 157 mm (H) × 74 mm (D) (excl. projections)
Weight: Approx. 1 kg (incl. internal battery)
