Measurement range:Positive pressure: 0 to 3500 kPa; Negative pressure: -80 to 0 kPa
Measurement display range: To 4200.00 kPa
Resolution: 0.01 kPa
Measurement accuracy(6 months after calibration. Tested after zero calibration): Positive pressure: ±(0.01% of reading + 0.15 kPa)/Negative pressure: ±(0.2% of reading + 0.08 kPa)
Measurement accuracy (1 year after calibration. Tested after zero calibration): Positive pressure: ±(0.01% of reading + 0.30 kPa)/Negative pressure: ±(0.2% of reading + 0.09 kPa)
Response time: 2.5 s or less
Allowable input: 2.7 kPa abs to 4500 kPa gauge
Internal volume: Approx. 6 cm3
Temperature coefficient: ±(0.001% of reading + 0.001% of full scale)/°C or less
Influence of positional setup: Zero-point drift ±0.3 kPa or less
Measurement fluid: Gas and liquid (non-corrosive, non-flammable, non-explosive, and non-toxic fluids)
Measurement fluid temperature: -10 to 50°C
Pressure sensor: Silicon resonant sensor
Pressure sensor element: Diaphragm
Pressure display units: kPa and other units(Pa, hPa, MPa, mbar, bar, atm, mmHg, inHg, gf/cm2, kgf/cm2, mmH2O@4°C, mmH2O@20°C, ftH2O@4°C, ftH2O@20°C, inH2O@4°C, inH2O@20°C, Torr, psi )
Input port: Rc 1/4 or 1/4 NPT female thread (selectable)
Measurement unit material: Diaphragm: Hastelloy C276 and input port: SUS316
Dimensions: Approx. 264 (W) x 188 (H) x 96 (D) mm, excluding protrusions
Weight: Approx. 2kg (including batteries)
