YOKOGAWA CL235 Clamp meter (AC 600A; True RMS)

AC current: 400/600A; 1.5+5 (50/60Hz)

DC current: 400/1000A; 1.0+5

AC voltage: 40/400/600V; 1.5+5 (50/60Hz)

DC voltage: 40/400/600V; 1.0+5

Crest factor: accuracy 3

Resistance: 400/4000Ω; 1.0+5, Beeps at below 20Ω(continuity check)

Frequency: 10～3000Hz; 1.5+5

Method of detection:True RMS

Display:LCD(Digital display:3999 counts)

Response time:Approx. 2 seconds

Range switching:auto-range

Data hold:On all range

Peak hold: On AC/DC current range, AC/DC voltage range

Operating temperat ure and humidity :0-40;, 90% RH or less (no condensation)

Effect of conductor position: 2% or less

Safety standard:Conforms EN61010-1, EN61010-2-031, EN61010-2-032

Circuit voltage:600Vrms or less

Withstanding voltage:6300V AC for 5 sec

Power supply:6F22(006P)9Vx1 or 6LR61x1

Batttery life:Approx. 15 hours (continuous)

Consumed current:Approx. 15mA

Sleep function:Automatically powered down in about 30 minutes after the last switch operation

Diameter of measurable conductor:33mm at maximum

Dimensions:Appro. 91(W)x210(H)x40(D)mm

Weight:Approx. 450g

Accessories:User's manual, batteries, carrying case(93032), Test Lead (98071)
