AC current: 40mA/400mA, 400A(0～350A), 400A(350～400A); 1.0+5 (50/60Hz) at 40mA/400mA, 400A(0～350A)
Method of detection:Mean value
Display: LCD(Digital display:3999 counts)*
Response time:Approx. 2 seconds
Range switching:Manual-range
Data hold: On all range
Peak hold: On all range
Operating temperature and humidity :0-40oC 85% RH or less (no condensation)
Effect of external magnetic field: 10mA or less in proximity to a 15mm-dia conductor carrying 100A
Effect of conductor position:40/400mA range:Within 5dgt at every part inside the jaw400A range, 0 to 250A:Within ± 0.5%rdg ± 5dgt at every part inside the jaw section
Effect of residual current: 12mA or less in proximity to a 10mm-dia conductor carrying 100A
Safety standard:Conforms EN61010-1, EN61010-2-032
Circuit voltage:300Vrms or less
Withstanding voltage:4240V AC for 5 sec
Power supply:R0-3(UM-4) 2 or LR03 2
Batttery life:Approx. 40 hours (continuous)
Consumed current:Approx. 13mA
Auto power-off: Approx. 10 minutes
Diameter of measurable conductor:40mm at maximum
Dimensions:Approx. 81(W)185(H)40(D)mm
Weight: Approx. 270g
Accessories:User's manual, batteries, carrying case(93030)
