Capacity (optional): 10, 20 kN
Unit (Switchable): kgf, lbf, N, kN, kPa, MPa
Load Resolution: 1/200,000 (or 1/300,000 specified by user)
Load Accuracy: ±0.25%
Load Range: Rangeless (full scales at the same amplification)
Stroke (exclude the grips): 1100 mm
Effective width: 410 mm
Test Speed: 0.001~1000 mm/min or 0.001~1500 mm/min selectable
Speed Accuracy: ±0.1%
Stroke Resolution: 0.00004 mm
Sample Rate: 200 times/sec
Communication Interface: USB
Motor: AC servo motor
Dimension (WxDxH):
Main Unit (Height exclusive of footpad): 75 × 78 × 232 cm
Computer / Desk: 109 × 65 × 116 cm
Weight (approx.):
Main Unit: 223 kg
Computer / Desk: 50 kg
Power: 1∮, 220V, 15A, 50Hz/60Hz or specified by user
