Max load: 2000KN
Load range: 20-2000kN
Load resolution: 1/200000
Load accuracy: ≤±1%
Deformation accuracy: ≤±1 %
Driving method: Hydraulic system
Max. Tensile space: 750mm
Clamps for flat specimen: Thickness 0 – 40mm
Clamps for round specimen: Diameter Ø 12-60mm
Max. Effective Compression space: 600mm
Compression plate diameter: Ø 148mm
Max. Bending test effective space: 600mm
Ram stroke: 250mm
Crosshead lifting speed: 280mm/min
Testing Speed control range: 0.5-50mm/min
Load measuring mode: Load cell
Displacement measuring mode: Photoelectric encoder
Deformation measuring mode: Extensometer
Power supply: 380VAC, 50Hz, 3-Phase
