Input Power: 230V AC, 50Hz
Operating Temperature: 15°C to 45°C
DC Voltage Ranges: 200mV, 2V, 20V, 200V, 1000V
AC Voltage (45 Hz to 1000 Hz) Ranges:200mV, 2V, 20V, 200V, 1000V
DC Current Ranges: 2mA, 20mA, 200mA, 2A, 10A.
AC Current ( 45 Hz to 1000Hz ) Ranges: 2mA, 20mA, 200mA, 2A, 10A.
Frequency: 45Hz to 1 kHz
Fixed Resistance: 1 Ω,10 Ω, 100 Ω, 1k Ω, 10k Ω, 100k Ω, 1M Ω, 10 MΩ,100 MΩ
Fixed Capacitance: 1nF, 10nF, 100nF, 1μ F, 10μF
RPM (Non Contact): 60,000 RPM Non Contact Type
V/A Selection: By Toggle Switch
Range Selection: By Rotary Switch
Setting: V/A setting by multiturn Coarse & fine potentiometers, Frequency by potentiometer, Accuracy(@ 15°C to 30°C, RH<70%)
DC Voltage: ±0.2 % of Rdg±5 Dgt.
AC Voltage: ±0.3% of Rdg±10 Dgt, Frequency: 0.1 Hz
Resistance: ±0.25%, Capacitance/Inductance: ±5%
RPM(Non Contact Type): ±0.1%±5 Dgt
Accessories: X 100 AC/DC current coil for clamp on meters calibration up to 1000A
Dimensions:W:400 X D:400 X H: 170 mm
Weight:19kg
