Polarization: RHCP (Right-Hand Circularly Polarized)
Dimensions: 915 mm x 305 mm x 8 mm
Connector: SMA female side fly lead (300 mm/1 ft.)
Housing Material: Flame-retardant ABS
Anti-static Protection: Yes, DC grounded
Weight: 2.4 kg/5.29 lbs. Gross: 2.8 kg/6.17 lbs.
Frequency Range: EU: 865 – 868 MHz / US: 902 – 928 MHz
VSWR (Return Loss): 1.4 typical
Gain: 9 dBiC typical
Front to Back Ratio: 24 dB
3 dB Beam Width: 20° in xz-plane, 80° in yz-plane
Maximum Power: 6 Watts
Axial Ratio: 2 dB
Operating Temperature: -20° to +55°C
Storage Temperature: -30° to +65°C
Standard: IP65
Nominal Impedance: 50 Ω
Antenna Detection: 10 K Ω resistance
