Dimensions: 8.0in. Hx3.7in. Wx5.2 in. D
20.3cm Hx9.4cm Wx13.2cm D
Weight: 11.6oz./330g
Input voltage range: 4.5 to 5.5VDC Host powered;
4.5 to 5.5VDC External power supply
Current: Operating current at nominal voltage (5.0V): 321mA (typical)
Standby current (idle) at nominal voltage (5.0V): 70mA (typical)
Color: Midnight black
Supported host interfaces: USB, RS232, Keyboard Wedge, TGCS (IBM) 46XX over RS485
Keyboard support: Supports over 90 international keyboards
Imager field of view: 48°Hx30.6°V nominal
Image sensor: 1280x800 pixels
Minimum print contrast 16% minimum reflective difference
Skew tolerance: +/- 60°
Pitch tolerance: +/- 60°
Roll tolerance: 0°-360°
Graphics format support: Images can be exported as Bitmap, JPEG or TIFF
Image quality (A4 Document): 116 PPI on an 8.3x11.7in./21.0x29.7cm document @ 8.0in./20.3cm
Environmental sealing: IP52
