Dimensions (H x D x W): 28.3 x 94.2 x 54.6 mm
Weight: 7.76 oz / 195 g
Power supply:
External supply: 10–30 VDC, 313 mA max @ 24 VDC (7.5 W)
PoE supply: Class 2
Configurable I/O:
Two opto-isolated inputs: IN 1.2
Two opto-isolated outputs: OUT 1.2
Housing material: Industrial blue anodized aluminum
Interfaces:
One M12 X-Coded 1000/100/10 Mbps Ethernet
One M12 12-pin Power/GPIO/RS-232
Communication protocols: Ethernet/IP, PROFINET, Modbus TCP, TCP/IP, RS-232
User indicators: Decode status LEDs, Power LED, Online/Run LED, Ethernet status LED; Beeper
Image sensor: 1/4 inch CMOS, global shutter, 1280 x 800, 3.0 µm square pixels, Monochrome
Acquisition rate: Up to 60 frames/second
Aimer: Amber LED; circular pattern
Illumination: Two red LEDs (660 nm) or two white LEDs (2700 K)
Imager field of view: 6.0 mm liquid lens: 35° H x 26° V nominal
Operating temperature:
32 °F to 113 °F (0 °C to 45 °C), external power 10–30 VDC (duty-cycle dependent)
32 °F to 113 °F (0 °C to 40 °C), PoE (duty-cycle dependent)
Storage temperature: –40 °F to 158 °F (–40 °C to 70 °C)
Enclosure rating: IP65 and IP67
Humidity: 5% to 90% RH, non-condensing
Shock resistance: EN 60068-2-27, 30 g; 11 ms; 3 shocks per axis
Vibration resistance: EN 60068-2-6, 14 mm @ 2–10 Hz; 1.5 mm @ 13–55 Hz; 2 g @ 70–500 Hz; 2 h per axis
1D barcode reading: Codabar, Code 39, Code 93, Code 128, Interleaved 2 of 5, MSI Plessey, UPC/EAN
2D barcode reading: Aztec, Data Matrix, DotCode, MaxiCode, PDF417, Micro PDF417, QR Code, Micro QR
OCR reading: Deep learning–based OCR via licensed add-on. Supports Latin characters (A–Z, a–z, digits, or symbols: ! # $ % & ( ) * + , - . / : ; < = > ? @ [ ] ^ _ ` { | } ~ ” ’ \ € £ ¥)
