Dimensions (H x D x W): 54.0 x 64.0 x 91.4 mm
Weight: 14.1 oz / 400.0 g
Keyboard: USB HID
Configurable I/O:
Four opto-isolated GPIO: GPIO0, 1, 2, 3
Five non-isolated GPIO: GPIO4, 5, 6*, 7*, 8*
Housing material: Industrial blue anodized aluminum
Interfaces:
One M12 X-Coded 1000/100/10 Mbps Ethernet
One M12 12-pin Power/GPIO/RS-232
One M12 5-pin External Light Power & Control/GPIO
One USB 3.0 SuperSpeed Type-C with DisplayPort Alt Mode
Communication protocols: Ethernet/IP, PROFINET, Modbus TCP, TCP/IP, RS-232
User indicators:
360° decode/job status LEDs, Power LED, Online/Run LED, Focus Warning LED, Error LED, Ethernet Status LED; Beeper
Image sensor:
2.3 MP: 1/2.3 inch CMOS, global shutter, 1920 x 1200, 3.0 µm square pixels, Monochrome
5.1 MP: 1/2.5 inch CMOS, rolling shutter, 2592 x 1952, 2.2 µm square pixels, Monochrome
Acquisition rate:
2.3 MP: Up to 60 frames/second
5.1 MP: Up to 30 frames/second
Aimer: Red Class II Laser; 8-point sunburst pattern
Illumination (field replaceable modules):
Eight red LEDs, 660 nm
Eight blue LEDs, 470 nm
Eight infrared LEDs, 850 nm
Eight white LEDs, 2700 K (color temperature)
Mixed module: Four red LEDs 660 nm + Eight infrared LEDs 850 nm + Four blue LEDs 470 nm + Eight white LEDs 2700 K
External illumination supported
Imager field of view: Liquid lens 6.8 mm, 46° H x 29° V nominal
Operating temperature:
32 °F to 113 °F (0 °C to 45 °C), external power 10–30 VDC (duty-cycle dependent)
32 °F to 113 °F (0 °C to 40 °C), PoE (duty-cycle dependent)
Storage temperature: –40 °F to 158 °F (–40 °C to 70 °C)
Enclosure rating: IP65 and IP67
Humidity: 5% to 90% RH, non-condensing
Shock resistance: EN 60068-2-27, 30 g; 11 ms; 3 shocks per axis
Vibration resistance: EN 60068-2-6, 14 mm @ 2–10 Hz; 1.5 mm @ 13–55 Hz; 2 g @ 70–500 Hz; 2 h per axis
1D barcode reading: Codabar, Code 39, Code 93, Code 128, Interleaved 2 of 5, MSI Plessey, UPC/EAN
2D barcode reading: Aztec, Data Matrix, DotCode, MaxiCode, PDF417, Micro PDF417, QR Code, Micro QR
OCR reading: Deep learning–based OCR via licensed add-on. Supports Latin characters (A–Z, a–z, digits, or symbols: ! # $ % & ( ) * + , - . / : ; < = > ? @ [ ] ^ _ ` { | } ~ ” ’ \ € £ ¥)
