Direct access to our certified experts
Print Technology: Thermal Transfer
Resolution: 230 dpi
Max Print Width: 2.2 in./56 mm
Print Speed: 8 in./203 mm per second
Connectivity Interface: Field installable RS-232 auto-sensing Serial, factory installed or field installable wireless dual radio – 802.11ac Wi-Fi and Bluetooth Classic 4.2
Memory: 512 MB Flash; 256MB DDR3 SDRAM
Barcodes: 1D, 2D
Media Roll Size:
Maximum Outer Diameter: 5.00 in./127 mm
Core Inner Diameter: 0.5 in./12.7 mm and 1.0 in./25.4 mm standard, 1.5 in./38.1, 2.0 in./50.8 mm and 3.0 in./76.2 mm using optional adapters
Ribbon Roll Length: 984 ft./300 m; 243 ft./74 m
Dimensions (L x W x H): 242.9 mm L x 138.7 mm W x 169.2 mm H
Weight: 3.59 lb./1.629 kg
Media Sensors: Full width, movable reflective/black mark sensor; multi-position gap/transmissive sensor
Printing Languages: ZPL II; EPL 2; XML; ZBI; PDF Direct
Battery: Powers printer to support full-shift printing at max print speed; supports all media handling options
Operating Temperature: 40° to 105° F/4.4° to 41° C
Storage Temperature: -40° to 140° F/-40° to 60° C
Humidity: 5% to 95% non-condensing
1D Barcodes: Code 11, Code 39, Code 93, Code 128, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2- or 5-digit extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Codabar and Planet Code
2D Barcodes: Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, MicroPDF, Aztec
Fonts and Graphics: 16 resident expandable ZPL II bitmap fonts, two resident ZPL scalable fonts, five resident EPL2 expandable fonts, native open-type font support, Unicode compliant. Chinese units include SimSun Simplified Chinese font 64 MB user available non-volatile memory, 8 MB user available SDRAM
