Direct access to our certified experts
Measuring volume: 300 x 200 x 200 mm3
Length measurement error MPE(E):
in 1D: 1.6 µm + L/200 µm
in 2D: 1.9 µm + L/150 µm
in 3D: 2.4 µm + L/150 µm
Software: ZEISS CALYPSO
2D optical camera sensor: ZEISS Discovery.V12
Option
standard 100: working distance 87 mm, 0.5 x - 6.3 x, sensor resolution 0.9 μm, FoV max.: 16,1 mm x 12,0 mm
scout 160: working distance 55 mm, 0.8 x - 10 x, sensor resolution 0.6 μm, FoV max.: 10,1 mm x 7,5 mm
scout 240: working distance 30 mm, 1.2x - 15 x, sensor resolution 0.4 μm, FoV max.: 6,7 mm x 5,0 mm
Tactile sensor: ZEISS VAST XXT
Option
VAST XXT TL 1:radial stylus length up to 40 mm (star stylus); stylus tip diameter of 0.1 to 8 mm
VAST XXT TL 3: radial stylus length up to 65 mm (star stylus); stylus tip diameter of 0.3 to 8 mm
Video
