Temperature Specifications
Temperature Control Range: -40℃~+150℃
Temperature Fluctuation: ±0.5℃
Temperature Decrease Rate: 150.0℃~-40℃ Approx. within 100mins 1.0~3.0℃/min
Temperature Increase Rate: -40.0℃~+150.0℃ Approx. within 60mins 3.0~5.0℃/min
Temperature Uniformity: ±1.0℃（-40℃~100.0℃）; ±1.5℃（100.1℃~150.0℃）
Humidity Specifications
Humidity Control Range: 20.0%RH~95.0%RH
Humidity Fluctuation: ±1.0% RH
Humidity Uniformity: ±2.0% RH
Material / Components
Interior Material: 1.2mm Thick Stainless Steel Plate (SUS304)
Exterior Material: 1.2mm Cold-rolled Steel Plate / Powder coating
Insulation Material: 100mm Thick Polyurethane Foam + 10mm Thick Glass Wool
Blower: Centrifugal Fan (Impeller Fan)
Compressor: Hermetic Tecumseh Compressor
Condenser: Air-cooled Type
Refrigerant: R404A / R23 / R508
Evaporator: Finned-tube Heat Exchanger
Heater: Nickel-chromium Alloy Heating Wire
Humidifier: Steam Humidifier
Dimensions:
Chamber Capacity: 300(W) * 300(H) * 250(D)
External Dimensions (W*D*H): 440(W) * 740(H) * 885(D)
Weight: 85kg
Power Supply Specifications: 220V/AC, 50/60Hz, 12A
Controller: Proprietary (Self-developed) Controller
