Temperature:
Temperature Range: 0℃～180℃
Temperature Fluctuation: ±0.5℃
Cooling Rate: 180.0℃～-70.0℃ 1.0～3.0℃/min (Nonlinear)
Heating Rate: -70.0℃～180.0℃ 3.0～5.0℃/min (Nonlinear)
Temperature Uniformity: ±1.5℃ (-40.0℃～100.0℃); ±2.0℃ (100.1℃～180.0℃or-40.0℃～-70.0℃)
Humidity:
Humidity Range: 10.0%RH～98.0%RH (10% RH at temperatures above 60℃）
Humidity Fluctuation: ±1.0% RH
Humidity Uniformity: ≤ ±3.0%(＞75%RH) ≤ ±5.0%(≤75%RH）
Material:
Internal Material: SUS304 Stainless Steel
External Material: Cold-rolled Plate, Powder Coating
Heat Insulation: Polyurethane Foam (100mm) + Glass Wool (10mm)
Fan: Centrifugal Fan (Impeller Fan)
Refrigeration Compressor: Hermetic Compressor (Tecumseh)
Cooling Mode: Air Cooling or Water Cooling
Refrigerant: R404A / R23
Evaporator: Finned-tube Exchanger
Heater: Nickel Chrome Strip Heater
Humidifier: Steam Humidifier
Size:
Interior Size (mm) W*H*D: 600 * 750 * 500
Outer Size (mm) W*H*D: 800 * 1680 * 1290
Volume（L): 225
Weight（kg): 300
Working Temperature: +5 ~ 35℃
Power Supply: AC220V 50Hz
Safety Specifications
* Adjustable over-temperature protection for test samples.
* Heater dry-heating over-temperature protection.
* Humidifier dry-heating over-temperature protection.
* Humidifier water-shortage over-temperature protection.
* Compressor overload protection.
* Ultra-high pressure protection.
The equipment automatically shuts down upon malfunction. The leakage protection function cuts off the main power supply.
Controllers
Korea Samwon TEMI-1500, TEMI-2500, TEMI-2700
* TEMI-1500: Ethernet and RS232 interface (only one selectable); (5.0-inch controller)
* TEMI-2500: Ethernet, RS232 interface, RS485 interface; (5.7-inch controller)
* TEMI-2700: Ethernet, RS232 interface, RS485 interface; (7.0-inch controller)
