Capacity (Optional): 50N,100N,250N,500N,1,2.5,5kN
Unit (switchable): N,kN,kgf, Lbf
Load Resolution: 1/25,000
Accuracy Grade of Machine: 1 Level
Max Stroke (Exclude the Grips): 1000mm
Effective Width: No Limit
Test speed: 1-500 mm/min, others (Customized)
Speed accuracy ± 1%
Displacement Resolution: Stroke: 0.00125 mm/Extensometer: 0.025 mm
Motor: AC frequency control motor
Transmission Rod: High accuracy of ball screw
Displayer: Can display, print force value and max deformation value; automatically stop when sample breaks down, overload protection function.
Main Unit Dimension (WxDxH): 500x400x1860mm
Power: AC220/50HZ 5A or specified by user
