Resolution (H x V Pixels): 1280 x 960
Resolution: 1.2 MP
Sensor Type: onsemi AR0134 / Progressive scan CMOS
Sensor Format: 1/3 inch
Effective Sensor Diagonal: 6 mm
Pixel Size (H x V): 3.75 x 3.75 μm
Frame Rate (at Default Settings): 54 fps
Mono / Color: Color
Image Data Interface: USB 3.0, nominal max. 5 Gbit/s (SuperSpeed)
Synchronization: Via software trigger Via free run
Exposure Time Control: Programmable via the camera API
Camera Power Requirements: ≈1.3 W (typical) @ 5 VDC
Lens Mount: CS-mount
Size (ø x L): 38.8 x 28.2 mm
Weight: <60 g
Conformity: CE (includes RoHS), EAC, UL Listed, GenICam 2.x (including PFNC 1.x and SFNC 2.x), USB3 Vision, REACH, KC
Software: Basler pylon Camera Software Suite (version 4.0 or higher) Available for Windows, Linux x86, Linux ARM, macOS, and Android
